A100 Actuator for Motorized Ball Valve

Description

Actuators are normally closed by default.If you need normally open actuators,please contact us support@bacoengineering.com.

Please Buy A20 Actuator and Valve Body Together.

Please Buy A100 Actuator and Valve Body Together.

Please Buy CWX Actuator and Valve Body Together.

This List is for A100 Actuator Only.

Technical Parameter:

• Actuator Material: Engineering Plastics
• Sealing Material: EPDM and PTFE
• Cable Length: 0.5m
• Maximum Working Pressure: 10 bar
• Circulation Medium: Water,Oil,Gas
• Working Current: Max 500 mA
• Open/close Time: 3-5 sec.
• Max Torque: 10 N·m (A100 Series)
• Environment Temperature:-15~50 Celsius
• Liquid Temperature: -5~100 Celsius
• Protection Class: IP67

Application:

• HVAC
• Water treatment
• Chemical process
• Small industrial equipment for automatic control
• Regular watering the flowers, Timing humidification,Air compressor drain at regular time.

Features:

• Smart shape, Perform reliably, large output torque, Lifespan of 80,000-100,000 times, convenience for all kinds of requirements.
• Float ball design, no leak, large flow, the valve is bi-directional ball valve, regardless of inlet and outlet , most suitable for heavy dirt and long time no action.
• High protection class, can work in moist conditions.
• POM cooperate with metal gear, the POM gear is used in high-speed level to reduce noise, At the same time metal gear is applied at the low-grade to ensure the reliability of the gear.
• Electrical and mechanical limit integrated design, accurate localization, high consistency, put an end to swing of valve.
